Schuhe für Bagger, Grouser, Gleisbolzen und -muttern 4F3651 Verschleißfestigkeit
Produktdetails:
| Herkunftsort: | China |
| Markenname: | Real TIG ，NB TIG |
| Zertifizierung: | ISO |
| Modellnummer: | 4F3651 |
Zahlung und Versand AGB:
| Min Bestellmenge: | 100 Stück |
|---|---|
| Verpackung Informationen: | Standard-Holzgehäuse 1050*710*840 |
| Lieferzeit: | 15-20 Tage |
| Zahlungsbedingungen: | T/T |
| Versorgungsmaterial-Fähigkeit: | 1000000pcs pro Monat |
|
Detailinformationen |
|||
| Material: | 40Cr | Oberfläche: | Schwarzer Sauerstoff |
|---|---|---|---|
| Zulassung: | 12,9, 10,9, 8,8 | P/n: | 4F3651 |
| Größe: | 1/2 ' UNC-13*1/2“ | Gewicht: | 0.08kg |
| Hervorheben: | Schrauben und Muttern für Baggerbahnen |
||
Produkt-Beschreibung
4F3651 Gleisschraube, -mutter und -spülmaschine für Unterbauteile der Klasse 12,9 der Klasse 8,8 und der Klasse 10.9
Schraubschrauben und Muttern
werden zur Verbindung von Gleitketten, Gleitschuhen und anderen Unterbauteilen verwendet
8Schraubschrauben der Klasse.8 und 12.9 haben folgende Vorteile:
Korrosionsbeständigkeit, starke Abriebsbeständigkeit und lange Lebensdauer.
| Verbrauch | Messung | In den meisten Fällen ist der Wert des Erzeugnisses zu messen. | Zulassung | Material |
| 8H7504 | 1/2" UNF-20X38 | 0.06 | 12.9 | 40cr |
| R24688 | 1 / 2 "UNF-20X40 W | 0.07 | 12.9 | 40cr |
| AC231 70097287 | 1/2" UNF-20X43 B | 0.07 | 12.9 | 40cr |
| IN2760 616191C | 1/2" UNF-20X43 | 0.07 | 12.9 | 40cr |
| 2A3223 | Ein zweieinhalb Zentimeter UNF-20X47 | 0.08 | 12.9 | 40cr |
| AC1119 70644688 | 1/2" UNF-20X49 B | 0.1 | 12.9 | 40cr |
| 6S3419 FT888 | 1/2UNF-20NUT ((19X15) | 0.04 | 45 | |
| 4K7038 | 9/16" UNF-18X42 | 0.1 | 12.9 | 40cr |
| AC82 R15309 | 9/16" UNF-18UNFx49 B | 0.11 | 12.9 | 40cr |
| 7H3596 CR429 | 9/16" UNF-18X51 | 0.11 | 12.9 | 40cr |
| IN1199 61699C1 | 9/16" UNF-18x54 | 0.12 | 12.9 | 40cr |
| 5P4684 CR3623 | 9/16" UNF-18x73 | 0.14 | 12.9 | 40cr |
| 5A3187 | 9/16" Unf-18x76 | 0.15 | 12.9 | 40cr |
| FT2728 76015987 | 9/16" unf-18x85 B | 0.16 | 12.9 | 40cr |
| 7K2017 CR1968 | 9/16" unf-18nuT ((22X18) | 0.05 | 10.9 | 40cr |
| Einheit für die Berechnung der in Absatz 1 Buchstabe a genannten Kosten | 5/8" UNF-18x46 | 0.13 | 12.9 | 40cr |
| 7H3597 | 5/8" unf-18x51 | 0.14 | 12.9 | 40cr |
| Zulassung | 5/8" unf-18x54 | 0.15 | 12.9 | 40cr |
| 5H8756 616207C1 | 5/8" unf-18x57 | 0.16 | 12.9 | 40cr |
| 9G3110 AC226 | 5/8" unfx57B | 0.16 | 12.9 | 40cr |
| 3T8601 CR4357 | 5/8" UNF-18x67 B | 0.17 | 12.9 | 40cr |
| 9G8592 CR5573 | 5/8" unf-18x83 B | 0.2 | 12.9 | 40cr |
| 5A4104 3P2274 | 5/8" unf-18x89 | 0.2 | 12.9 | 40cr |
| 3T8580 | 5/8" unf-18x91 B | 0.21 | 12.9 | 40cr |
| 1M1408 CR1250 | 5/8" UNF-18nuT | 0.06 | 10.9 | 40cr |
| 1S1859 CR1105 | 3/4" UNF-16X55 | 0.23 | 12.9 | 40cr |
| 7H3598 | 3/4" UNF-16X61 | 0.24 | 12.9 | 40cr |
| 6V1792 CR4441 | 3/4" UNF-16X61 B | 0.26 | 12.9 | 40cr |
| 1S8804 | 3/4" UNF-16x63 | 0.25 | 12.9 | 40cr |
| 7F8619 CR331 | 3/4" UNF-16X70 | 0.265 | 12.9 | 40cr |
| 1061642 | 3/4" UNF-16X75 B | 0.29 | 12.9 | 40cr |
| Die in Absatz 1 genannten Bedingungen gelten nicht für die in Absatz 1 genannten Erzeugnisse. | 3/4" UNF-16X76 | 0.28 | 12.9 | 40cr |
| 6V1793 CR4440 | 3/4" UNF-16X81 B | 0.3 | 12.9 | 40cr |
| Die in Absatz 1 genannten Bedingungen gelten nicht. | 3/4" UNF-16X99 B | 0.34 | 12.9 | 40cr |
| 5A7524 1D1295 | 3/4" UNF-16X102 | 0.35 | 12.9 | 40cr |
| 9S1838 CR3326 | 3/4" UNF-16X105 B | 0.36 | 12.9 | 40cr |
| 2P9670 CR3119 | 3/4" UNF-16X112 | 0.35 | 12.9 | 40cr |
| 6T1441 CR4699 | 3/4" UNF-16X124.5 B | 0.41 | 12.9 | 40cr |
| 1S1860 CR1967 | 3/4UNF-16NUT ((28x19) | 0.08 | 10.9 | 40cr |
| 7H3599 9M7444 | 7/8" UNF-14x67 B | 0.37 | 12.9 | 40cr |
| mit einer Breite von nicht mehr als 20 mm | 7/8" UNF-14x76 | 0.4 | 12.9 | 40cr |
| 7T2748 | 7/8" unf-14x85 B | 0.43 | 12.9 | 40cr |
| 6V1723 CR4135 | 7/8" UNF-14x89 B | 0.44 | 12.9 | 40cr |
| 6V1724 CR4132 | 7/8" UNF-14x95 B | 0.46 | 12.9 | 40cr |
| 9W9058 CR4789 | 7/8" UNF-14x115 B | 0.53 | 12.9 | 40cr |
| 8S0395 CR2709 | 7/8: UNF-14x121 B | 0.54 | 12.9 | 40cr |
| 6V1725 CR4133 | 7/8" UNF-14x127 B | 0.56 | 12.9 | 40cr |
| 2S2140 CR1969 | 7/8UNF-14NUT ((33x22.5) | 0.12 | 10.9 | 40cr |
| 7G6442 CR4136 | 7/8unf-14 Nuss ((33x33.5) B | 0.15 | 10.9 | 40cr |
| 2M5657 9M7445 | "UNF-14X75 B" | 0.55 | 12.9 | 40cr |
| 3T6308 CR4029 | "UNF-14X84 B" | 0.57 | 12.9 | 40cr |
| 6T2638 CR4670 | "UNF-14X90 B" | 0.6 | 12.9 | 40cr |
| 6V1726 CR4036 | "UNF-14X101 B" | 0.65 | 12.9 | 40cr |
| 6V1727 CR3858 | "UNF-14x110 B" | 0.68 | 12.9 | 40cr |
| 7T2283 CR4669 | "UNF-14x123 B" | 0.74 | 12.9 | 40cr |
| 8S1723 CR2669 | "UNF-14x141 B" | 0.81 | 12.9 | 40cr |
| 6V1728 CR3859 | "UNF-14x148 B" | 0.84 | 12.9 | 40cr |
| 1S6421 CR1970 | "UNF-14NUT" (38x25) | 0.2 | 10.9 | 40cr |
| 7G0343 CR4037 | "UNF-14NUT ((38x39) B | 0.23 | 10.9 | 40cr |
| 7T1000 | 1-1/8" UNF-12X96 B | 0.85 | 12.9 | 40cr |
| 5p3968 | 1 1/8" Unf-12X107 B | 0.88 | 12.9 | 40cr |
| 7T0999/CR5258 | 1-1/8" UNF-12x134 B | 1.1 | 12.9 | 40cr |
| 7T0998/CR5257 | 1-1/8" UNF-12x164 B | 1.2 | 12.9 | 40cr |
| 9W4480 | 1-1/8" UNC-7x139.5 | 1.1 | 12.9 | 40cr |
| 5P8221 CR3835 | "UNF-12NUT" | 0.3 | 10.9 | 40cr |
| 6T8853 | 1 3/8" UNF-12x110 | 1.5 | 12.9 | 40cr |
| 6I8648 | 1-3/8" unf-12x121 | 1.6 | 12.9 | 40cr |
| 6T8521 CR5640 | 1-3/8" unf-12x153 | 1.8 | 12.9 | 40cr |
| 6T8520 CR5639 | Einmal im Jahr. | 2 | 12.9 | 40cr |
| 3T6292 CR5638 | 1 bis 3/8" Unf-12-Nuss ((54X45) | 0.7 | 10.9 | 40cr |
| 101-32-11210 | M12X1.5X40 | 0.07 | 12.9 | 40cr |
| FT887 571946 | M12x1,25-Nuss ((19x15) | 0.03 | 10.9 | 40cr |
| 205-32-21210 | M14X1.5X45 | 0.1 | 12.9 | 40cr |
| 203-32-21220 | M14X1.5X56 | 0.11 | 12.9 | 40cr |
| OK21K | M14X1.5NUT ((22X15) | 0.04 | 10.9 | 40cr |
| 205-32-51120 | M16X1.5X50 | 0.14 | 12.9 | 40cr |
| 130-32-21252E | M16X1.5X82 | 0.2 | 12.9 | 40cr |
| 5I6125 | M16X1.5NUT(24X16) | 0.06 | 10.9 | 40cr |
| mit einer Breite von nicht mehr als 20 mm | M18X1.5X55F | 0.19 | 12.9 | 40cr |
| mit einer Breite von nicht mehr als 20 mm | M18X1.5X60 | 0.2 | 12.9 | 40cr |
| 135-32-11210 | M18x1,5x65 | 0.22 | 12.9 | 40cr |
| 79039445 FT982 | M18X1.5NUT(27X18) | 0.08 | 10.9 | 40cr |
| 20Y-32-11210 | M20X1.5X53F | 0.23 | 12.9 | 40CR |
| 9W3619 | M20X1.5X55D | 0.25 | 12.9 | 40cr |
| 79035814-FT2110/154-32-21323 | M20X1.5X62F | 0.26 | 12.9 | 40cr |
| 6Y0846 | M20X1.5X63 | 0.27 | 12.9 | 40cr |
| 14y-32-11210/71401192 | M20X1.5X65F | 0.27 | 12.9 | 40cr |
| FT1100 | M20X1.5X68 | 0.27 | 12.9 | 40cr |
| 154-32-21260/km799 | M20x1.5x117 | 0.4 | 12.9 | 40cr |
| 9W3361-FT2111 | M20X1.5NUT(28X22) | 0.08 | 10.9 | 40cr |
| 207-32-51210 | M22X1.5X56F | 0.3 | 12.9 | 40cr |
| 71428357 | M22X1.5X62F | 0.32 | 12.9 | 40cr |
| 6Y9024 | M22X1.5X67D | 0.33 | 12.9 | 40cr |
| 76007851/FT2205 | M22X1.5X70F | 0.35 | 12.9 | 40cr |
| 170-32-11212 | m22x1,5x76 | 0.36 | 12.9 | 40cr |
| 9W4381-CR5923 | M22X1.5NUT(32X22) | 0.13 | 10.9 | 40cr |
| 208-32-51210 | M24X1.5X65F | 0.38 | 12.9 | 40cr |
| 21M-32-11260 | M24X1.5X72 | 0.42 | 12.9 | 40cr |
| 175-35-11210/KM378 | M24X1.5X76 | 0.46 | 12.9 | 40cr |
| 175-32-41260 | M24x2.0x125.5 | 0.61 | 12.9 | 40cr |
| 175-32-81192 | M24X1.5X105 | 0.57 | 12.9 | 40cr |
| 175-32-81312 | M24X1.5X127.8 | 0.65 | 12.9 | |
| 178-32-11220 | M24X1.5NUT ((35X24) | 0.15 | 10.9 | 40cr |
| 195-32-11210/KM263 | M27X1.5X82 | 0.62 | 12.9 | 40cr |
| 6Y7432 | M27X2.0X90 | 0.66 | 12.9 | 40cr |
| 195-32-41210/KM6361 | M27x2.0x93 | 0.68 | 12.9 | 40cr |
| 195-32-41431/km1085 | m27x1,5x140 | 0.9 | 12.9 | 40cr |
| 195-32-23140 | m27x2.0x145 | 0.92 | 12.9 | 40cr |
| 195-32-31241/km651 | m27x1,5x152 | 1 | 12.9 | 40cr |
| 195-32-11221 | M27X1.5NUT ((41X27) | 0.23 | 10.9 | 40cr |
| 195-32-41220/KM1151 | M27X2.0NUT ((41X35) B | 0.27 | 10.9 | 40cr |
| 195-32-61210/km1999 | M30X2.0X96 | 0.85 | 12.9 | 40cr |
| pc1250/KM2348 | M30X2.0X102 | 1.1 | 12.9 | 40cr |
| 4314542 | m30x2.0x128 | 1.2 | 12.9 | 40cr |
| 195-32-61350/km2000 | m30x2.0x167 | 1.4 | 12.9 | |
| Siehe auch: | M30X2.0NUT ((46X38) B | 0.46 | 10.9 | 40cr |
| 198-32-41330/KM3193 | M33X2.0X114 | 1.3 | 12.9 | 40cr |
| 3034712S | M33X2.0X145 | 1.5 | 12.9 | 40cr |
| 3O347421 | M33X2.0X162 | 1.7 | 12.9 | 40cr |
| 198-32-31340 | M33X2.0X185 | 1.8 | 12.9 | 40cr |
| 198-32-31220 | M33X2.0NUT ((50X42) B | 0.5 | 10.9 | 40cr |
| 198-32-31220 | M33X2.0NUT ((50X42) B | 0.5 | 10.9 | 40cr |
